Brief Technical Description
The company specializes in producing a VC mixer which can improve the mixing efficiency, enable the particles to be fully mixed and dispersed, and reach the micron-scale with uniform mixing. This equipment adopts the following design principles: the mixer has a conical mixing cavity and is equipped with a central rotating shaft, whose rotation speed can reach 30 meters per second. The centrifugal force is generated by the speed of the rotating shaft to push the product to the inner wall of the mixing chamber. At that time, the conical shape of the cavity causes the product to move upward along the inner wall. The product is guided to the center of the mixer by a specially designed mixing machine cover, and then falls back to the bottom of the mixing chamber to restart a new round of mixing process. The entire cavity of the VC mixer is protected by a jacket, which can accurately control the temperature and avoid overheating of the material. The stirring shaft is on the top, and is easy to be cleaned and operated. It has a wide range of use, such as strong mixing of slurry, liquid and powder, spheroidization, dispersion, crushing, drying, granulation and coating.
The company provides VC mixers from 5 liters test equipment to 50, 150, 250, 500 liters volume production equipment。
Main Claims:：
The VC mixer is characterized by a cylinder body (2), a conical cylinder body, with a mixing shaft (3) in the center of the cylinder, a feeding port (1) at the upper right, a stirring blade (4), which is fixed in a spiral shape on the mixing shaft (3), and has a small gap with the cylinder body (2). The discharge port (5) is at the bottom of the cylinder body. The outside of the cylinder body (6) is provided with a jacket.
